feature:
Modern design, light weight and compact size.
Collect 12 leads at the same time, and display 12-channel ECG waveform on the full screen.
7-inch color screen, button type and touch type (optional).
Sensitive filters for ADS, HUM and EMG.
Automatic measurement, calculation, analysis, and waveform freezing. Automatic analysis and automatic diagnosis can
Reduce the burden on doctors and improve work efficiency.
Automatically adjust the baseline to obtain the best record.
Thermal printer, 80mm printing paper, synchronous printing.

Specification:
Name: Monitor
Voltage tolerance: ±500m V
Time constant: >3.2s
Frequency response: 0.05Hz~150Hz
Input impedance: ＞50MΩ
Input circuit current: ≤ 0.1µ A
Patient auxiliary current: <10µ A (220V-240V/50Hz)
CMRR: ≥100dB, with AC filter
A/D resolution A/D: 12bits/1000HZ
Acquisition method: 12 leads are collected at the same time, and the 12-channel ECG waveform is displayed on the full screen.
Sensitivity: 5, 10, 20mm/mV
Heart rate range: 30BPM~300BPM
Heart rate calculation accuracy: ±1 BPM
AC power supply rated voltage: 100V-240V
Rated frequency: 50Hz / 60Hz, rated power: 60VA
Built-in lithium rechargeable battery
Rated voltage: 12V
Rated capacity: 2000mAh
Fuse: F2AL 250V

packing list:
ECG machine x1
Instruction manual x1
